Automatic Plywood Core Veneer Drying Line

Shine Biomass Veneer dryer is product in the design of the continuous roller pressure type of hot air cylinder,it is using the most advanced continuous pressurized contact and its working principle is veneer veneer drying technology in steel tube under the clamping roller,two by preheating the oven temperature to 140,and then enter the upper and lower roller and through the hot air pipe to the single board upside down between hot high pressure blowing for quick dry,so you can make the veneer smooth moisture content after drying of uniform,And it has the characteristics of high temperature roller and wet veneer direct contact heat transfer, high thermal efficiency and small thermal loss.

The hot air blower adopts 5.5KW axial flow fans, and the air volume can reach 46000m³/hour, which not only fully guarantees the air volume required for drying, but also reduces the total power. Reducing the power consumption of the entire equipment to be lowest.

The traditional veneer dryer is easy to drop chain, card chain, veneer deviation, heat exchange device is easy to plug. These will result in low thermal energy utilization and poor product uniformity. Moreover, its transmission device is complex and maintenance is difficult, which virtually increases the production cost.
Shine roller type veneer drying machine utilizes the latest international technology of pressurized contact veneer drying, which has the advantages of simple operation, safety and practicality, stable operation, easy maintenance, hot-pressing-levelling–drying once completed, etc. The use of hot air circulation has greatly reduced the operating costs of factories, improved the quality of sheet materials and increased the production volume. The roller plays a role in ironing the veneer. After the veneer is dried, the veneer is flat and the moisture content is relatively uniform. When the veneer is located between two roller sets, the lateral direction can be freely contracted, the occurrence of cracks is reduced, and the drying quality is good. The heat dissipation process is carried out in a flat state. In the benign physical process of wood shrinkage, the veneers do not warp and deform, the breakage rate is low, and the yield rate is high.

Heat Exchanging System

Product Parameters

Customer Case

The Main advantages of our Biomass Burner

1.Smokeless, energy saving and environmental

2.Low cost，waste wood does not need to be dried in the sun and can be burned directly, reducing the cost of drying.

3.High temperature, large yield, full combustion

4.high efficenency ,under the traditional way, the venee easy to crack after long-term exposure. and it’s affected by the weather; however, veneer dryer drying is not easy to deformation, low damage rate, high product rate.

The installation

Our Factory

Product Packaging

Certificate

Q&A

1.How much does it cost to dry 1m³ veneer?
About $12, including labor, fuel, electricity, will fluctuate with local prices.
2.How to choose a product that is most suitable for me？
A：Our company have professional engineer to select the most suitable product according to your capacity and areas, saving your time and cost.
3.Will it be difficult to install？
A: We will send professional engineers to guide. In remote situations, engineers will video assist workers with installation. There have been many remote success stories.
4.Can I see the real equipment and factory?
Yes. We can provide the location of the equipments that have put into production, and we contact and communicate with the users for you. Hence you can see our real equipment and its effects.
