New veneer dryer machine adopts automatic temperature control and speed regulation system, which can adjust the veneer delivering speed and drying temperature automatically in accordance with different veneer thicknesses and moisture content to achieve an ideal veneer drying effect.
New veneer dryer machine is exclusively invented by Shine Machinery and is a very new biomass burner roller dryer that features the lowest drying veneer cost among traditional roller dryers and various heat sources. Wet veneer is not easy to store, easy to rot, and insects. Poor adhesion in the subsequent bonding process, easy to deglue. If the moisture content is too high, a lot of water vapor is easy to appear in the process of pressing the hot press. If the wet veneer is not dried, the quality of the veneer is poor, affecting the subsequent gluing process, and easy to damage the equipment. So veneer drying is a crucial process. The traditional way of air drying can no longer keep up with the needs of modern engineering. Large-scale plywood is more suitable to use the dryer for veneer drying.
Veneer Dryers are crucial in the plywood process. In the process of innovation in the production of wet wood dryers, we continue to introduce advanced technology and continuously improve product performance. Our product portfolio includes belt dryers for peeled veneers, roller dryers, and press dryers for smooth and flat decorative veneers. The wood veneer dryer can be used to dry core veneer and face veneer of rubberwood, eucalyptus, birch, teak, all kinds of hardwood, softwood veneer, etc. Shine veneer drying machine is renowned for consistently producing high-quality veneer with uniform dry moisture content. The dried veneer by Shine veneer roller dryer machine has a uniform moisture content, flat with no buckle or end waviness, free of splits. The shrinkage of the dried veneer is kept to a minimum percentage. And the veneer surface is in good condition before gluing for plywood-making machines. Shine veneer dryers machine is equipped with a biomass burner, which can burn waste wood directly and save drying costs mostly. Our core veneer dryer can be designed by our professional team in line with users’ special capacity requirements.
Advantages of Veneer Dryer Machine
1. The biomass burner, a patented product independently developed by our company, can directly use crushed wood waste as fuel to provide a heat source for the wood veneer dryer, which is energy-saving and environmentally friendly, and greatly reduces the drying core veneer and face veneer cost.
2. The well-developed heat exchange system for the wood core veneer drying machine fully improves the energy utilization rate and saves unnecessary energy waste. It has obtained the national invention patent.
3. The control cabinet has automatic temperature control and speed regulation system, which can accurately control the final moisture content of the veneer during the veneer drying process. Simple operation and low failure rate.
4. The temperature in the burner is 40-60℃ higher than that of the traditional veneer dryers (steam type, thermal oil type), and the drying temperature is controlled at 140-180 ℃, which shortens the veneer drying time and increases the veneer drying output.
5. After veneer drying, the dried veneer is smooth, with no cracks, wrinkles, or end ripples.
6. Shrinkage and hardening of the veneers are kept to a minimum and veneer collapse and honeycomb structure are avoided when veneer is dried by our roller veneer dryer heated by a biomass burner.
7. We have a professional R&D team that can design different roller dryers models as per the customers’ special requirements.
8. The perfect after-sale service team can supply 24 hours online service to ensure our customers’ problems can be addressed in no time.
9. Semi Auto Feeder provides systematic and precise feeding of individual trays to the dryer. The feeder receives the top sheet of core veneer from each stacks and uniformly distributes them onto each individual deck of the dryer infeed section. With the use of semi auto feeder and veneer collection system, the production efficiency is greatly improved, and the labor intensity of production personnel can also be reduced. The automatic feeder will need one person only at the front end of the veneer dryer and 2 persons for the veneer collection at the discharge end of the veneer dryer.
10. Automatic veneer in feeding system can realize automatic feeding veneer, continuous drying, high working efficiency, intelligent operation management, simple and convenient operation, can greatly reduce the number of labor force and reduce the labor intensity of production personnel, improve production efficiency and reduce production costs, achieve full automation of single board production. Only 1-2 people are on duty to solve the problem of large number of manual personnel into the board and large labor intensity.
11. Semi-automatic plate collection system can achieve continuous work, high efficiency, at any time to ensure the clean veneer, reduce the number of labor and reduce labor intensity, improve production efficiency. Reduce production costs.
Our dryer feeding system can be semi-automatic or fully automatic, and the degree of automation according to customer requirements, meets the requirements of veneer production and design. The vacuum assist system lifts wet veneers and transports them to the dryer at high feed rate. Even into the board, spread the deck, improve the efficiency. The feeding speed is adjusted according to the actual situation. To avoid board jam, keep the board direction consistent with the machine. High-precision air distribution and even flow are used inside the heating chamber. The horizontal jet circulation system can make the veneer evaporate water evenly to the maximum extent. The process of evaporating water evenly and slowly ensures the surface of the veneer is smooth, the size is uniform, and the moisture content is the same. On the stacking line, vacuum belts transport the dried veneers to different stacking stations and classify veneers of different quality grades. Humidity and thickness detection systems can be used upstream or downstream of the dryer. It can also be used directly after veneer peeling. It can monitor veneer humidity and thickness at the same time through the non-contact sensor.
Customers from all over the world visit
1. All kinds of dryer types can be made in accordance with customer’s specific requirements
2. All prices are based on FOB.QINGDAO, China
3. Payment: by T/T or L/C.
4. All the Parameters above are just for reference, for they are updating all the time
5. Package: Standard packing
6. Warranty: All the machine enjoys one year’s warranty, in this period
7. Any problems with the machine, please feel free to contact us. We will try our best to make it.
1) 24 hours online services
2) Provide the VIDEO with Pre-sale and after-sales services:
1) Provide the free consultation of all types of Core Veneer and Face Veneer Mesh Dryer Machine
2) According to the client’s special requirements, offering a reasonable production plan and free design to help to select the equipment.
3) Welcome to visit our factory any time
Services during the sales:
1) Inspect the machine before leaving the factory.
2) Oversea installation and debug the equipment
3) Train the first-line operators.
1. install and debug the veneer drying machine
2. Provide the free technical assistance
3. Engineers Door-to-door service is possible
4. Sufficient spare parts available at favorable pricing
1. What will it take to dry 1 cubic meter of veneer using your biomass burner veneer dryer?
About $6-12, including labor, fuel, and electricity, will fluctuate with local prices.
2. How to choose a veneer dryer that suits me best？
A： Our company has professional engineers to select the most suitable product in line with your capacity and areas, saving your time and cost.
3. Will it be difficult to install？
A: We will send professional engineers to guide of covid 19 permits. In remote situations, engineers will video assist workers with installation. There have been many remote success stories around the world.
4. Can I visit your dryer site and factory?
Yes. We can provide the location of the equipment that has been put into production, and we contact and communicate with the users for you. Hence you can see our real equipment and its effects.
Shandong Shine Machinery Co.,Ltd has more than 100 employees. The company’s headquarters is located in Gaotang Industrial Park, a beautiful water city in the north of the river, and the production plant covers a total area of 100 mu. The company specializes in the production of wood veneer dryers, bridge formwork, automated livestock and poultry breeding equipment, special equipment for the production of construction materials, etc. With the advantages of many years of research and development, production, service and production capacity, the company has always been in the leading position in the same industry. Shine Machinery provides high performance, high quality products and one-stop service for customers, and can tailor different products to meet the needs of customers in different situations and provide customers with fast and optimized system solutions.
The company is far-sighted and implements a modern enterprise management system, making use of new sales concepts and service systems. With an annual investment of 20 million in scientific research, the company joins forces with various industrial universities in China to study the application of high-end technology, so that the various products of shine Intelligence are always at the forefront of technology in the industry. The company is very strict about the quality of its products, and every piece of equipment it produces meets the ISO9001 quality management system certification. The company has large CNC gantry milling machine, data flame cutting machine, plane mill, universal milling machine, vertical and horizontal sawing machine and other large production equipment, the introduction of foreign advanced technology, so that “Shine” equipment with reasonable design, reliable performance, high quality, low energy consumption, easy to operate, high output and many other advantages. The company’s products have won the praise of our customers for their high precision and high cost performance.
